SMC · Regulators
AR30-F02H-D
excl. VAT · €35,72 incl. 20% VAT (BG)
Free delivery from €200
Free delivery from €200
Genuine SMC part · official SMC partner
VAT invoice, pay by card or bank transfer
Delivery up to 2 weeks
Need volume pricing or a special version? Request a quote →
| Part number | AR30-F02H-D |
|---|
MODULAR STYLE REGULATOR
Modular-style Regulator Up to 0.85 MPa set pressure Maximum flow rate up to 20000 l/min (ANR, 0.7MPa).
Features
- ISO 8573-1:2010 compliant
- Up to 0.85 MPa set pressure
- Maximum flow rate up to 20000 l/min (ANR, 0.7MPa).
Specifications
- Part number: AR30-F02H-D
- Item number: 02193471
- Options: H (w/Set Nut, for Panel Mount)
- Pressure Units: Standard (Name Plate, Caution Plate for Bowl, and Pressure Gauge: MPa)
- Body Size: 30
- Set pressure: 0.05 to 0.85 MPa Setting
- Knob: Downward
- Port Size: 02 (1/4)
- Exhaust Mechanism: Relieving
- Backflow Function: None
- Flow Direction: Left to Right
- Thread: F (G)
- Lead time: 4 days
- Country of origin: JP
