SMC · Process Valves
SX11-DJ
excl. VAT · €45,83 incl. 20% VAT (BG)
Free delivery in BG from €80
Free delivery in the EU from €200
Genuine SMC part
| Part number | SX11-DJ |
|---|---|
| Valve Mounting | 1 (Screw Mount Type) |
| Filter | w/o Filter |
| Flow Rate/Operating Frequency | D (Flow 50 L/min; Power 4W; Max. Op Frequency 350Hz) |
| Lead Wire | J (1000 mm) |
| Lead time (days) | 21 |
| Minimum order quantity | 1 |
| Country of origin | JP |
| TARIC code | 8481209090 |
- At SMC we are speeding ahead with the launch of our rapid response two port valve, the SX10 series. Ideal for sorting machinery, the SX10 is so quick to respond that it can signal ON at 0.45 ms and OFF at 0.4 ms. It can also support greater productivity with frequency rates of up to 1,200 cycles per second and cost savings due to its long life capability of more than 5,000 million cycles and low power consumption of just 4 W. Available in several flow and frequency options, the SX10 offers versatility and is compact in design with easy installation and removal thanks to a quick disconnect mounting option. Its flexibility means the SX10 is ideal for colour sorting machinery, plastics recycling and waste separation and gluing, dosing, packaging and vacuum applications.
Key features
- High speed response: ON at 0.45 ms, OFF at 0.4 ms.
- Long service life: 5 billion cycles.
- Low power consumption: 4W.
- High frequency: 1200Hz.
- Mounting types: quick disconnect and screw mount type.
