SMC · Process Valves
VXA2130G-01F-1
excl. VAT · €93,59 incl. 20% VAT (BG)
Free delivery from €200
Free delivery from €200
Genuine SMC part · official SMC partner
VAT invoice, pay by card or bank transfer
Delivery time: On request
Need volume pricing or a special version? Request a quote →
Total
| Part number | VXA2130G-01F-1 |
|---|---|
| Size | No.1 |
| Orifice | 3 (4.5 Mm) |
| Style | 0 (Normally Closed) |
| Option | G (Stainless Steel Body, NBR Seal) |
| Port Size | 01 [1/8 (6A)] |
| Thread | F (G) |
| Bracket | None |
| Lead time (days) | 27 |
| Minimum order quantity | 1 |
| Country of origin | JP |
| TARIC code | 8481209090 |
- Direct air operated, 2 and 3 port valve series VXA can be used with a wide variety of fluids. The manifold for the VXA21/22 series is available in a common SUP style or individual SUP style (for vacuum use). The VXA31/32 series manifold is individual ported. Valves for both are easily replaced without changing existing piping.
Key features
- Direct air operated 2 port valve
- Proper selection of body and sealing materials
- permits application of a wide variety of fluids
- Valve body available in N.C. or N.O.
- Port size : Rc(PT)1/8
- Pilot pressure: 0.25 to 0.7MPa
- Compatible with high viscosity fluids (500cSt)
Documents
More part numbers in this series
VVX233D05DX500€3.692,99VXP2380-14F-5D-Q€425,83VXA3244N-03F-B€208,97VX070-022€1,75VXA3135V-00€118,84VXA3124H-01-B€155,55VXA2230V-02F-1-B€102,21VXA3114H-01N-B€155,56VXA2121V-00-1€81,58VXA3114V-01F€118,70VXA2241A-00-1€67,30VXA2120-01-1€43,94VXA2121-00-1€43,94VXA2130A-01F-1-B€56,63VXA2120A-01F-1-B€56,63
