- The IZN10E is SMC's nozzle ionizer. The nozzle ionizer emits an air-assisted cone of static eliminating ions for focused targets 2 inches or smaller, up to 20 inches away. The nozzle can be used with an optional sensor and monitor to suspend emission when static elimination is complete, or when the target is not present. Available with a high flow or enery saving nozzle, or female threads to attach an accessory. The cartridge can be removed without tools for needle cleaning or replacement. Slim, compact design is suitable for installation in tight spaces.
Key features
- Slim & Lightweight.
- Offset voltage: ±10V.
- Nozzle variations.
- With external switch input function (2 inputs).
- Easy maintenance.
- Intermittent control timer.
Specifications
- Nozzle Type: 11 (Female Threads for Piping, Rc1/8)
- Input/Output Specifications: P (PNP Input/Output)
- Port Size: 06 (ø6, Metric Size)
- Power Supply: Power Supply Cable, 3m
- Bracket: w/o Bracket
- Made to Order: None
Additional information
- Part number: IZN10E-11P06
- Lead time (days): 5
- Minimum order quantity: 1
- Country of origin: JP
- TARIC code: 8543709099
