- Applications generating harmful levels of static electricity now have the ideal solution following the launch of our new portable fan type ionizer -Series IZF10. Extremely compact and lightweight and without the need of a compressed air supply, this fan type Ionizer is suitable for a wide range of applications including workbench mounting. Series IZF10 achieves and ion balance of ±13V, or less, and is available in a low noise type (29dB(A)) or a fast static removal type (1.5 seconds). Fitted with two alarm functions, plus a trimmer for adjusting the ion balance, monitoring the Series IZF10´s operating performance cannot be easier and ease of on-site maintenance has also been considered as it is also possible to clean the Ionizers electrodes by simply removing the cartridge case.
Key features
- Air flow adjustment function added.
- Signal output for emitter contamination detection function added.
- Slim design.
- Offset voltaje (Ion balance): ±13 V.
- Rapid static neutralisation: 1.3 seconds.
Specifications
- Flow Rate Adjustment: Without Flow Rate Adjustment
- Air Flow: 660 l/min (With Flow Rate Adjustment
- Output: P (Output PNP)
- Power Supply Cable: With Power Supply Cable (3 m)
- Bracket: B (With Bracket)
Additional information
- Part number: IZF10-P-B
- Lead time (days): 5
- Minimum order quantity: 1
- Country of origin: JP
- TARIC code: 8543709099
